Sanitary Stainless Steel Union Type Check Valve for Manufaturing

Basic Info

Model NO.	XS-00036
Function	Nrvr Silence
Sealing Form	Gland Packings Globe Valve
Flow Direction	Reversing
Standard	ISO, SGS, CE
Application	Industrial Usage, Water Industrial Usage, Household Usage, Milk, Beer, Juice, Phramacy
Connection Standard	SMS,DIN,Ldf,ISO
Size	3/4"~6",DN19~DN150
Quality Material	SS304,SS304L,SS316,SS316L
Max. Working Pressure	10 Bar
Seal Ring	EPDM,or Silicon Is Required
Body O-Ring	NBR or EPDM. Is Required
Operating Mode	Manual
Transport Package	Shrink Wrap-Carton Case-Exporting Plywood Case
Specification	SMS, DIN, Idf, ISO
Trademark	XUSHENG
Origin	Made in Wen Zhou China
HS Code	8481804090
Production Capacity	5000sets/Month

Product Description

Sanitary Stainless Steel Union Type Check Valve for ManufaturingIt is widely applied to many fileds, such as beer, beverage, dairy food, fruit juice, pharmacy, biological etc.

Specification

Standard	SMS,DIN,IDF,ISO
SMS,DIN,IDF,ISO	SS304,SS304L,SS316,SS316L
Size	3/4"~6",DN19~DN150
Seal ring of stem	EPDM. OR SILICON is required
Connection ends	Butt-welded,clamped,male ends,union ends
External surface	Bright gloss,dull gloss
Bright gloss,dull gloss	Manual
Working temperature	-20Celsius degree~+135Celsius degree
Max. working pressure	10Bar

Performance and merit:

1. Valve wall steamlined design,a smaller flow resistance,a flow smooth.
2. Flexible seat seal.Sealing a better effect.
3. Spring reduction and design,installation location unrestricted
4. Middle with clamp or flange design for easy maintance and clean.
5. Forging valve,the pressure better.

Our Service

On Samples	Buyer bear the air fee, but this fee will be reduced from order directly
On After Sales	Free replacement if there is any quality problem
On Delivery	Never delay delivery time
On Materials	Ensure material pure
Ensure material pure	Welcome

Welcome to contact us for Sanitary Stainless Steel Welded Check Valve
